Discontinued
We have discontinued this product permanently. Please find suggested replacement products from below section.
LED 2 ft Linear High Bay Light - 110 W - 320 W MH Equivalent - 15,400 Lumens - 5000K
Part Number:
LHBD3-50K110H
Manufacturer Part Number:
Discontinued
Features
- Streamlined, lightweight profile for simplified installation
- Delivers high efficiency at 140 lumens per watt
- Suspension mounting kit included for versatile installations
- DLC 5.1 Premium
In-House Test Lab
Each of our products undergoes rigorous testing in our in-house test lab to verify quality and specifications.
Hassle-Free Returns & Exchanges
Industry-Leading 45-Day Return & 90-Day Exchange Policies*
Free Lighting Layout Consultation
If you're looking for a customized, energy-efficient lighting layout, our industrial & commercial lighting experts can provide an assessment tailored to your floorplan.
Overview
The LED linear high bay delivers high-output illumination within a slim, energy-efficient design, perfect for applications in warehouses, manufacturing facilities, and gymnasiums. Its white steel housing and prismatic polycarbonate lens ensure even, uniform light distribution. This fixture offers exceptional energy savings, with a high efficacy of 140 lumens per watt, making it an ideal replacement for 320 W metal halide fixtures. For even greater efficiency, the high bay is compatible with an optional motion sensor.
Product Details:
- White steel housing and a prismatic polycarbonate lens
- IP20 rated for damp or dry location only
- 0-10V Dimming
- 120-277 VAC
- Certified by UL
- DLC 5.1 Premium
- 5-year warranty
Documents
LHBD3 User Manual
LHBD3-50K110H IES File Applications:
- Big Box Retailers
- Convention Centers
- Distribution Centers
- Factories
- Gymnasiums
- High Bays
- Manufacturing Plants
- Packaging Facilities
- Warehouses
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
This product meets higher lumen and efficacy standards than are required for a normal DLC® classification. This classification also requires submission of a driver IN-SITU temperature measurement test (ISTMT) along with information regarding integral controls.
This product has been certified by Underwriter Laboratories to their engineering and safety standards.
Need help?
Use our Lighting Layout Tool to see how this product illuminates your space.
Specifications
| Ambient Operating Temperature | -20 to 50 °C (-4 to 122 °F) |
|---|---|
| Beam Angle | 90° |
| Brand | Super Bright LEDs |
|
CCT
CCT
|
5000K |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact and energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else that may be involved confidence that the product is safe and will work well in their application. The most common UL and ETL certifications relate to safety and installation, although they do also provide some sanitation-related certifications (using NSF standards). Another common certification body is the DLC, which specializes in certifying the performance of a light—mainly related to environmental impact and electrical efficiency. Learn more about different certification types here . |
Certified by UL, DLC Premium |
|
CRI
CRI
|
80+ |
|
Current Draw
Current Draw
Current draw is calculated using the following formula: W/V = A, where W = the amount of power your light needs (wattage), V is the electrical system voltage (e.g., 120V AC), and A = amps. An ampere or amp (A) is the standard unit for electrical current. A milliamp (mA) equals one-thousandth of an amp, or 1000 mA is equivalent to 1 A.
Choosing LED fixtures with the correct amperage ensures safe and proper operation, preventing damage or injury. We recommend having all electrical components and fixtures installed by a certified professional electrician or lighting technician in compliance with all relevant standards and regulations. |
400 mA @ 277 VAC, 920 mA @ 120 VAC |
| Dimmable | Yes |
|
Dimmer Type
Dimmer Type
|
0-10V |
| Efficacy | 140 lm/W |
|
Environmental Rating
Environmental Rating
|
Non-weatherproof, Suitable for Damp Locations |
| Equivalency | 320 Watt Metal Halide |
| Finish | White |
| Input Connection Type | Pigtail |
| Integrated Surge Protection | 2 kV |
|
IP Rating
IP Rating
|
IP20 |
| LED Color | Cool White |
| Rated Life (L70) | 50000 Hours |
| Length | 24 in. (2 ft) |
| Lumens | 15400 Lumens |
| Microwave Motion Sensor | Optional |
| Operating Voltage | 120-277 VAC |
| Power Factor | ≥0.9 |
| Product Materials | Polycarbonate Lens, Steel Housing |
| Product Weight | 5.9 lb (2.7 kg) |
| UL File Number | E366643 |
| Warranty | 5 Year |
| Wattage | 110 Watts |
| Wire Gauge | 18 AWG |
