80W LED High Bay Retrofit Bulb - 11,600 Lumens - 250W MH Equivalent - E39 Mogul Screw Base - Ballast Bypass - 5000K
Part Number:
HBA-50K80-E39C
Manufacturer Part Number:
Discontinued
Similar Products Available Today
Features
- High-lumen LED upgrade from traditional bulbs
- Four LED panels offer wide-area illumination
- Easily installs into E39 mogul sockets
- Type B ballast bypass
Most Popular Compatible Products
Overview
The 80W LED High Bay Retrofit Bulb is engineered for efficient and reliable lighting, delivering 11,600 lumens at 145 lm/W. This bulb is designed for easy installation with an E39 mogul screw base and features a Type B ballast bypass for streamlined retrofitting. Its energy-efficient design reduces power consumption by over 30%, making it a cost-effective upgrade for high bay lighting applications. The robust black aluminum housing and clear polycarbonate lenses offer durability, while the IP64 weatherproof rating ensures reliable performance in both indoor and outdoor environments. With a wide 110° beam angle, this bulb is ideal for illuminating large areas such as workshops, garages, and warehouses.
Product Details:
- Black aluminum housing, clear polycarbonate lenses
- IP64 weatherproof rated
- E39 mogul screw base
- 2kV surge protection
- 120-277 VAC
- Certified by UL
- 5-year warranty
HBA-50K80-E39C Specification Sheet Dimensional Drawings
Applications:
- Factories
- Hangars
- High Bays
- Industrial Facilities
- Low Bays
- Warehouses
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
Specifications
| Ambient Operating Temperature | -40 to 55 °C (-40 to 131 °F) |
|---|---|
| Ballast Compatibility | Type B (Ballast Bypass) |
| Base Type | E39 (Mogul Base) |
| Beam Angle | 110° |
| Brand | Super Bright LEDs |
|
CCT
CCT
 |
5000K |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact and energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else that may be involved confidence that the product is safe and will work well in their application. The most common UL and ETL certifications relate to safety and installation, although they do also provide some sanitation-related certifications (using NSF standards). Another common certification body is the DLC, which specializes in certifying the performance of a light—mainly related to environmental impact and electrical efficiency. Learn more about different certification types here . |
Certified by UL |
|
CRI
CRI
 |
80+ |
|
Current Draw
Current Draw
Current draw is calculated using the following formula: W/V = A, where W = the amount of power your light needs (wattage), V is the electrical system voltage (e.g., 120V AC), and A = amps. An ampere or amp (A) is the standard unit for electrical current. A milliamp (mA) equals one-thousandth of an amp, or 1000 mA is equivalent to 1 A.
Choosing LED fixtures with the correct amperage ensures safe and proper operation, preventing damage or injury. We recommend having all electrical components and fixtures installed by a certified professional electrician or lighting technician in compliance with all relevant standards and regulations. |
290 mA @ 277 VAC, 670 mA @ 120 VAC |
| Efficacy | 145 lm/W |
|
Environmental Rating
Environmental Rating
Suitable for Dry Locations This marking indicates that you can use the light or component in a location not normally subject to dampness. This may include locations exposed to temporary dampness, such as a building under construction, provided that ventilation is adequate to prevent moisture accumulation. Use these fixtures in living rooms, bedrooms, offices, hallways, and similar areas. The marking may be "SUITABLE FOR DAMP LOCATIONS" or "DRY LOCATIONS ONLY."Suitable for Damp Locations Fixtures marked “SUITABLE FOR DAMP LOCATIONS” or “SUITABLE FOR WET LOCATIONS” can be installed in damp locations. A damp location is an exterior or interior location regularly or occasionally subject to moisture condensation on or around electrical equipment. It includes partially protected places such as covered patios and porches. Damp locations include any regularly muggy or humid area, such as above a kitchen sink or stove, and appropriately vented bathrooms near the tub or shower.Suitable for Wet Locations Fixtures and components marked "SUITABLE FOR WET LOCATIONS" can be installed in wet or damp locations. A wet location is anywhere water or other liquids may drip, splash, or flow on or against electrical equipment. A light marked "SUITABLE FOR WET LOCATIONS" may have additional markings that tell where and at what height it can be safely mounted. Uncovered outdoor areas like decks, gazebos, walls, and typical landscape lighting sites all fall under the heading of wet locations. |
Suitable for Damp Locations, Weatherproof |
| Equivalency | 250 Watt Metal Halide |
| Finish | Black |
|
IP Rating
IP Rating
 |
IP64 |
| LED Color | Cool White |
| Rated Life (L70) | 50000 Hours |
| Lumens | 11600 Lumens |
| Operating Voltage | 100-277 VAC |
| Power Factor | ≥0.9 |
| Product Materials | Aluminum Housing, Polycarbonate Lens |
| Product Weight | 1.9 lb (0.9 kg) |
| UL File Number | E477606 |
| Warranty | 5 Year |
| Wattage | 80 Watts |
