8” Commercial Deep Recessed LED Downlight - Ultra-High 95+ CRI - Selectable CCT and Wattage - Up to 200W Incandescent Equivalent - 0-10V Dimmable - Up to 3,200 Lumens
Part Number:
CDL8D-SW5AU-SP36M
Manufacturer Part Number:
$64.99
ea.
Was
In Stock
Austin
Account Manager
Empower Your Business
Exclusive benefits & tailored support await you.
Sign up for a Commercial Account today!
Features
- Deep recessed anti-glare design for optimal visual comfort
- Ultra-high 95+ CRI for superior color rendering
- Field-selectable CCT (2700K–5000K) and wattage (18W, 27W, 36 W)
- Spring clips included for quick ceiling installation
- IC-rated for safe contact with insulation
In-House Test Lab
Each of our products undergoes rigorous testing in our in-house test lab to verify quality and specifications.
Hassle-Free Returns & Exchanges
Industry-Leading 45-Day Return & 90-Day Exchange Policies*
Free Lighting Layout Consultation
If you're looking for a customized, energy-efficient lighting layout, our industrial & commercial lighting experts can provide an assessment tailored to your floorplan.
Related Products
See the difference
Ultra-high CRI lighting closely mimics sunlight, bringing out true colors
For any occasion
Available in a variety of lamps and fixtures, we have ultra-high CRI lighting to suit your needs
Save on energy, not quality
Get outstanding performance while cutting energy usage, and saving money
Overview
The 8" Commercial Deep Recessed LED Downlight delivers ultra-high 95+ CRI light for vibrant, accurate colors—ideal for retail environments, art galleries, and medical facilities. It has a deep recessed housing design that minimizes glare, promoting visual comfort in high-use areas. This downlight features selectable CCT (2700K, 3000K, 3500K, 4000K, 5000K) and wattage (18 W, 27 W, 36 W), allowing easy customization using switches on the fixture. With up to 3,200 lumens output, it serves as an energy-efficient replacement for 200W incandescent fixtures, reducing energy costs without compromising brightness. Installation is simple with included spring clips, and its IC-rating ensures safe contact with insulation for versatile use.
Product Details:
- Durable aluminum trim cone with white powder-coated trim ring
- Frosted polycarbonate lens
- Suitable for damp locations
- 120° beam angle
- IC-rated for direct contact with insulation
- 0-10V Dimmable
- 120-347 VAC
- ETL Listed
- 5-year warranty
CDLxD-SW5A User Manual Applications:
- Auditoriums
- Commercial Downlights
- Conference Halls
- Hospitality
- Hospitals
- New Construction
- Offices
- Retail Shops
- Schools
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
A product that bears an ETL-Certified label has been evaluated by a Nationally Recognized Testing Laboratory (NRTL) and meets national product safety standards. An ETL certification is accepted in the U.S. and in Canada.
Ultra-High CRI
Ultra-high CRI (Color Rendering Index) values mean a light source accurately renders colors. CRI measures how accurately a light source shows an object's true colors and is calculated on a scale from 0 to 100, with 100 indicating perfect color rendering matching the spectrum of natural sunlight. In contrast, a low CRI value indicates a less precise rendering. Color accuracy is essential for specific applications, such as portrait studios, retail stores, hospitals, medical and commercial offices, display cases, and warehouses, where telling the difference between similar colors is crucial.
Specifications
| Ambient Operating Temperature | -20 to 45 °C (-4 to 113 °F) |
|---|---|
| Beam Angle | 120° |
| Brand | Super Bright LEDs |
|
CCT
CCT
|
2700K, 3000K, 3500K, 4000K, 5000K, Selectable CCT |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact and energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else that may be involved confidence that the product is safe and will work well in their application. The most common UL and ETL certifications relate to safety and installation, although they do also provide some sanitation-related certifications (using NSF standards). Another common certification body is the DLC, which specializes in certifying the performance of a light—mainly related to environmental impact and electrical efficiency. Learn more about different certification types here . |
ETL Listed |
|
CRI
CRI
|
95+ |
|
Current Draw
Current Draw
Current draw is calculated using the following formula: W/V = A, where W = the amount of power your light needs (wattage), V is the electrical system voltage (e.g., 120V AC), and A = amps. An ampere or amp (A) is the standard unit for electrical current. A milliamp (mA) equals one-thousandth of an amp, or 1000 mA is equivalent to 1 A.
Choosing LED fixtures with the correct amperage ensures safe and proper operation, preventing damage or injury. We recommend having all electrical components and fixtures installed by a certified professional electrician or lighting technician in compliance with all relevant standards and regulations. |
167/250/333 mA @ 120 VAC |
| Dimmable | Yes |
|
Dimmer Type
Dimmer Type
|
0-10V |
| Efficacy | 90 lm/W |
|
Environmental Rating
Environmental Rating
|
Suitable for Damp Locations |
| Equivalency | 100 Watt Incandescent, 150 Watt Incandescent, 200 Watt Incandescent |
| Finish | White |
| Input Connection Type | Pigtail |
| Integrated Surge Protection | 2 kV |
| IC Rated | Yes |
|
IP Rating
IP Rating
|
IP20 |
| LED Color | Warm White, Natural White, Cool White, Selectable CCT |
| Rated Life (L70) | 50000 Hours |
| Lumens | 1600 Lumens, 2400 Lumens, 3200 Lumens |
| Operating Voltage | 120-347 VAC |
| Power Factor | ≥0.9 |
| Product Materials | Aluminum Housing, Polycarbonate, Steel |
| Product Weight | 1.8 lb (0.8 kg) |
| Warranty | 5 Year |
| Wattage | 18 Watts, 27 Watts, 36 Watts |
