10 W LED Flexible Gooseneck Loading Dock Light - 32” Stainless Steel Arm - 1,200 Lumens - 120 VAC - 5000K
Part Number:
LDL-50K10W-32
Manufacturer Part Number:
Discontinued
Features
- 32-inch flexible steel-arm
- Designed to fully illuminate trailers up to 53 feet
- Narrow 20° beam angle
- Reinforced steel frame for optimal stability
Most Popular Compatible Products
Overview
The 10 W Gooseneck LED Dock Light is designed for precise task lighting in commercial environments. Featuring a 32" flexible stainless steel arm, this fixture delivers focused lighting with a 20° beam angle, ensuring accurate illumination of trailer interiors up to 53'. The dock light generates 1,200 lumens, providing sufficient brightness for loading docks and warehouse settings. Its yellow aluminum housing and durable polycarbonate lens offer long-lasting performance, and the IP65 rating ensures suitability for wet locations. Keyhole slots and a 35” cord with a standard 5-15P plug, makes installation simple.
Product Details:
- Yellow aluminum housing with 32" stainless steel flexible arm
- Polycarbonate lens with an aluminum head for enhanced durability
- Precise 20° beam angle ensures focused illumination
- 35” power cord with 5-15P plug included
- Keyhole slots for quick and secure mounting
- IP65 waterproof rating for wet environments
- Operates on 120V AC
- Certified by UL
- 5-year warranty
LDL Specification Sheet Dimensional Drawings
Applications:
- Factories
- Industrial Facilities
- Loading Docks
- Safety Lighting
- Task Lighting
- Utility Lighting
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
Specifications
| Ambient Operating Temperature | -40 to 40 °C (-40 to 104 °F) |
|---|---|
| Beam Angle | 20° |
| Brand | Super Bright LEDs |
|
CCT
CCT
 |
5000K |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact and energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else that may be involved confidence that the product is safe and will work well in their application. The most common UL and ETL certifications relate to safety and installation, although they do also provide some sanitation-related certifications (using NSF standards). Another common certification body is the DLC, which specializes in certifying the performance of a light—mainly related to environmental impact and electrical efficiency. Learn more about different certification types here . |
Certified by UL |
|
Current Draw
Current Draw
Current draw is calculated using the following formula: W/V = A, where W = the amount of power your light needs (wattage), V is the electrical system voltage (e.g., 120V AC), and A = amps. An ampere or amp (A) is the standard unit for electrical current. A milliamp (mA) equals one-thousandth of an amp, or 1000 mA is equivalent to 1 A.
Choosing LED fixtures with the correct amperage ensures safe and proper operation, preventing damage or injury. We recommend having all electrical components and fixtures installed by a certified professional electrician or lighting technician in compliance with all relevant standards and regulations. |
83 mA |
| Dimmable | No |
| Efficacy | 120 lm/W |
|
Environmental Rating
Environmental Rating
Suitable for Dry Locations This marking indicates that you can use the light or component in a location not normally subject to dampness. This may include locations exposed to temporary dampness, such as a building under construction, provided that ventilation is adequate to prevent moisture accumulation. Use these fixtures in living rooms, bedrooms, offices, hallways, and similar areas. The marking may be "SUITABLE FOR DAMP LOCATIONS" or "DRY LOCATIONS ONLY."Suitable for Damp Locations Fixtures marked “SUITABLE FOR DAMP LOCATIONS” or “SUITABLE FOR WET LOCATIONS” can be installed in damp locations. A damp location is an exterior or interior location regularly or occasionally subject to moisture condensation on or around electrical equipment. It includes partially protected places such as covered patios and porches. Damp locations include any regularly muggy or humid area, such as above a kitchen sink or stove, and appropriately vented bathrooms near the tub or shower.Suitable for Wet Locations Fixtures and components marked "SUITABLE FOR WET LOCATIONS" can be installed in wet or damp locations. A wet location is anywhere water or other liquids may drip, splash, or flow on or against electrical equipment. A light marked "SUITABLE FOR WET LOCATIONS" may have additional markings that tell where and at what height it can be safely mounted. Uncovered outdoor areas like decks, gazebos, walls, and typical landscape lighting sites all fall under the heading of wet locations. |
Suitable for Damp Locations, Waterproof |
| Finish | Yellow |
| Input Connection Type | 3-Prong Wall Plug |
|
IP Rating
IP Rating
 |
IP65 |
| LED Color | Cool White |
| Rated Life (L70) | 50000 Hours |
| Lumens | 1200 Lumens |
| Mount Type | Surface Mount |
| Operating Voltage | 120 VAC |
| Power Factor | ≥0.5 |
| Product Materials | Aluminum Housing, Polycarbonate Lens, Steel |
| Product Weight | 3.5 lb (1.6 kg) |
| UL File Number | E507681 |
| Warranty | 5 Year |
| Wattage | 10 Watts |
